Barco® Coronis MDCG-2121 2MP 21.3" Grayscale Diagnostic Radiology PACS Monitor


Choose Your Option: K9601659-P-R
Setup:
Price:
- +
+ -
Request a Quote

Barco® Coronis MDCG-2121 2MP 21.3" Grayscale Diagnostic Radiology PACS Monitor

A popular choice of diagnostic display monitor, the Barco® Coronis MDCG-2121 provides a reliable, high-quality imaging solution for PACS, CT, MR, angiography, ultrasound, and orthopedic applications, at a good value.


Superior Image Presentation
The advanced, 10-bit architecture of the Barco® MDCG-2121 enables 1,024 shades of gray simultaneously out of an existing palette of 4,096 shades. This produces the most accurate image possible on the screen and helps subtle details pop with less panning or zooming. Uniform luminance technology maintains consistent brightness levels across the screen, from the center to corner, so that no abnormality goes undetected. Additionally, the anti-reflective, protective front cover improves image contrast while preventing damage to the screen and making disinfecting easier and safer for the electronic components.


Automatic Calibration and QA Checks
As you progress through your daily workflow free of interruptions, the integrated MediCal QAWeb® software automatically calibrates the Barco® MDCG-2121 in alignment with medical standards, including DICOM, and conducts QA checks. This keeps your equipment in peak diagnostic condition and maximizes uptime without any effort on your part.


Continuous DICOM Compliance in All Lighting Conditions
Whenever the lighting conditions around your workstation shift ever so subtly, the Barco® MDCG-2121 has you covered. Barco®'s patented ambient lighting compensation (ALC) technology a built-in, front-of-screen sensor continuously detects changes in the surrounding lighting and automatically adjusts monitor brightness in real-time to DICOM. I-Guard® technology further maintains DICOM compliance by correcting image quality, including grayscale values, in response to lighting changes.


Versatility
With the proper adapter, the Barco® MDCG-2121 is compatible with any graphics card and both Windows and Mac. As a result, you won't have to worry about the monitor's compatibility with your workstation, laptop, or PC.


Features at a Glance

  • 10-bit lookup table enhances grayscale visualization

  • Fantastic brightness and contrast

  • Excellent uniformity across the entire display

  • ALC and I-Guard technologies provide continuous, worry-free DICOM compliance under all lighting conditions

  • MediCal QA software automates calibration and QA.

Tech Specs

Manufacturer Barco®
MFG Part# K9601659
Screen Type Grayscale
Resolution 2MP (1600 x 1200)
Pixel Pitch 0.2700 x 0.2700 mm
Contrast Ratio 850:1
Aspect Ratio Hv 4:3
Calibrated Luminance 500 cd/m²
Max Luminance 1650 cd/m²
Calibration Auto (built-in front sensor)
Backlight Sensor Yes
Front Sensor Yes
Ambient Light Sensor Yes
Backlight CCFL lamps
Screen Technology TFT AM LCD Dual Domain IPS
Active Screen Size (DIAGONAL) 541 mm (21.3")
Active Screen Size (H x V) 432 x 324 mm (17.0 x 12.8")
Video Input Signals DVI
3D Tomosynthesis No
Viewing Angle (H, V) 178°, 178°
Mount Type VESA (100 mm)
Dimensions (W x H x D) 369 x 558 x 285 mm (14.5" x 21.9" x 11.2")
Power Consumption 54 W
Power Requirements 100–240 VAC, 1.5–0.6 A, 47-63 HZ
Weight 32.2 lbs (14.6 kg)
